Explore Seaory S22 card printer functions

The Seaory S22 is a fast, compact PVC ID card printer ideal for card printing offices of all kinds. This is an ideal solution for printing student ID cards, government ID credentials, employee ID cards, membership cards and customer loyalty cards.

S22 Desktop Dual-sided Card Printer

Dye Sublimation Direct-to-card Card printer

Defaulted print resolution: 300 dpi × 300 dpi

300 dpi × 600 dpi, 300 dpi × 1200 dpi print resolution optional

LCM control panel Support Multi-languages,128MB Memory

Available to set the direction of card input & output, Dual-side printing, Alarm for no cards and defective card slot

Body size: 383(L) × 174(W) × 208(H)mm ; N.W: 6.8 Kg

High quality , High efficiency

Monochrome printing :3~5s per card (Single-sided) / 7~12s per card (Dual-sided)

Full-color(YMCKO) printing :20s per card(Single-sided) /42s per card (Dual-sided)

Print dimension is ISO CR80(53.98mmx85.6mm) standard card

Input hopper capacity is 100pcs cards

Output hopper capacity is 50pcs cards

Defective card slot capacity is 30pcs cards

Creative design
Keep improving

Driver: support Windows XP/7/8/10/11, Windows Server 2003/2008/2012/2016,Linux

Card design software: ICARDE, support Windows XP/7/8/10/11

Concise design, friendly operation, powerful function

Databases connection available, completely independent intellectual property rights

Designed for large quantity & low cost printing

Black Monochrome Ribbon: 100m×60mm/200m×60mm, around 1,000/2,000 prints/roll

Gold, Silver, White, Red, Blue Monochrome Ribbons:100m×60mm,around 1,000 prints/roll

YMCKO ribbon full panel: 100 / 300 prints/roll

1/2 ymcKO ribbon: 450 prints/roll

1/2 ymcKOKO ribbon: 250 prints/roll

KO, 500 prints/roll

UV Ultraviolet Security Ribbon: 100m×60mm, around 1,000 prints/roll

Seaory S22 is a fast, compact PVC ID card printer

Variety of card encoding module

Magnetic stripe card encoding module: Support ISO7811 Hi-co/Low-co, 3-Track read & write

Dual interface chip card reading and writing module:

Support CPU card (ISO 7816, T=1 & T=0)

4 SAM slots (same as SIM card size complied with GSM 11.11)

Support contactless CPU card (ISO14443 TYPE A/B),PC/SC

Contactless ID card encoding module : Support 125KHz (Specified chip type)

UHF Chip card encoding module: Support EPC C1 GEN2/ ISO 18000 -6C Air interface protocol standard

Certifications

Product Name	S22 Desktop Dual-sided Card Printer
Print Method	Dye Sublimation Direct-to-card
Print Resolution	300 dpi x 300 dpi (300 dpi × 600 dpi, 300 dpi × 1200 dpi print resolution optional)
LCM Display	Chinese: 8 characters per line, 2 lines / English: 16 characters per line, 4 lines / Multi-language
Memory	128MB
Print Speed	Monochrome printing :3~5s per card (Single-sided) / 7~12s per card (Dual-sided) Full-color(YMCKO) printing :20s per card(Single-sided) /42s per card (Dual-sided)
Card Size	ISO-CR80（85.6mm x 53.98mm）
Card Thickness	0.3 - 1.05mm
Input Hopper Capacity	100pcs cards
Output Hopper Capacity	50pcs cards
Body Size	383 × 174 × 208mm
N.W	6.8Kg
Software	Driver: Support Windows XP/7/8/10/11, Windows Server 2003/2008/2012/2016, Linux, and NeoKylin, Kylin, UOS and other made-in-China operating system. Development Kit: Support Windows XP/7/8/10/11, Windows Server 2003/2008/2012/2016, Linux, and NeoKylin, Kylin, UOS and other made-in-China Operating System Card Design Software: iCARDE card design software, support Windows XP/7/8/10 operating systems
Interfaces	USB & Ethernet
Power	AC 100~240V, 50/60 Hz DC 24-25.5V, 2.7 A
Operating Condition	Regular running temp.:15℃-30℃（59-86℉),20%-65% RH Non-condensing Lowest / Highest running temp.:0℃（32℉）/40℃（104℉），20%-65% RH Non-condensing
Consumables	Black Monochrome Ribbon: 100m×60mm/200m×60mm Gold, Silver, White, Red, Blue Monochrome: Ribbons:100m×60mm YMCKO ribbon full panel: 100 / 300 prints/roll 1/2 ymcKO ribbon, 450 prints/roll; 1/2 ymcKOKO ribbon, 250 prints/roll KO, 500 prints/roll UV Ultraviolet Security Ribbon: 100m×60mm
Certificates	CCC, FCC, CE, ROHS, BIS, UKCA
Optional Encoding Module	Dual interface chip card reading and writing module: Support (ISO 7816, T=1 & T=0), 4 SAM slots (same as SIM card size complied with GSM 11.11), Support contactless CPU card (ISO14443 TYPE A/B),PC/SC Contactless ID card encoding module: Support read and write 125KHz RFID smart card (ATA5567, ATA5577, EM4469, EM4305, hitag-s and other common ID chip cards UHF Chip card encoding module: Support EPC C1 GEN2/ ISO 18000 -6C Air interface protocol standard Magnetic stripe card encoding module: Support ISO7811 Hi-co/Low-co, 3-Track read & write
