UHF Chip card encoding module

Support EPC C1 GEN2/ ISO 18000 -6C Air interface protocol standard
Operating frequency 840 ~ 960MHz, compatible with UHF RFID frequency bands in all countries and regions such as Europe, the United States, Japan, China, India and user-defined frequency bands
Output power: 5~20dBm, stepping 3dB, user can set it by themselves
USB to RS232 serial port communication (virtual serial port), communication speed up to 115200bps
Provide API interface function library and demonstration program, can support a variety of operating systems and language development platform, support online upgrade
Suitable for Seaory S series Card printers

UHF Chip card encoding module Specification.pdf

Magnetic Stripe Card encoding module

Multiple tracks data can be read and written simultaneously
Extra-long life of magnetic head and the whole module
With stable and reliable performance, can achieve read and write double check function
Comply with ISO 7811 magnetic card standard information format
Suitable for Seaory S series Card printers

Magnetic Stripe Card encoding module Specification.pdf

Print head

Specification: S series, direct-to-print, 300dpi
Printing method: Dye Sublimation direct to card
Effective print width :55mm
Suitable for Seaory S series Card printers

Locking card input hopper

Specification: Two locks; Maximum capacity 200 cards(0.76mm)
Size:180mm×57mm×182mm
Material: SECC, steel plate
Main function: increase the card quantity and prevent important cards from being stolen or lost
Suitable for Seaory S22S Card printer

Locking card input hopper Specification.pdf

Dual Interfaces Chip Card encoding module

Support contact and contactless chip card data read and write
Contains 4 SAM card slots which comply with the size of GSM 11.11 SIM card slot
Support ISO7816 contact chip card, Support ISO14443 TYPE A/B contactless CPU card
Support standard built-in RS232 and USB interface(HID driver free technology), Communication speed up to 115200bps
Provide universal interface function library, can support a variety of operating systems and language development platform, support online upgrade
Suitable for Seaory S series Card printers

Dual Interfaces Chip Card encoding module Specification.pdf

High capacity input hopper

Specification: Combined type; Maximum capacity 400 cards(0.76mm)
Size:106x72x245mm (After combined 3units)
Material: ABS, Black color
Suitable for Seaory S22K Card printer

High capacity input hopper Specification.pdf

Seaory S series full-panel YMCKO ribbon

Suitable for Seaory S20 S21 S22 S22K card printers
High resolution full-color image and black text printing effect ,not easy to fade
YMCKO ribbon panels: Yellow-Y ,Magenta-M,Cyan-C,Black resin-K ,Overlay-O
Printing card material:PVC or Composite PVC
100/300 Printers per roll (ISO CR80 53.98mm×85.60mm)
Cleaning roller and cleaning card are included

Seaory S series full-panel YMCKO ribbon Specification.pdf

Seaory S series half-panel 1/2ymcKO ribbon

Suitable for Seaory S20 S21 S22 S22K card printers
High resolution full-color image and black text printing effect ,not easy to fade
1/2ymcKO ribbon panels: Half-size Yellow-Y ,Magenta-M,Cyan-C panels ,Full size Black resin-K ,Overlay-O panels
Printing card material:PVC or Composite PVC
450 Printers per roll (ISO CR80 53.98mm×85.60mm)
Cleaning roller and cleaning card are included

Seaory S series half-panel 1/2ymcKO ribbon Specification.pdf

Seaory S series black monochrome ribbon

Suitable for Seaory S20 S21 S22 S22K card printers
black monochrome ribbon are primarily used for printing text and one-color line art on one or both sides of a card
Size:200mx60mm / 100mx60mm
2000 / 1000 monochrome prints per roll (ISO CR80 53.98mm×85.60m)
Printing card material:PVC or Composite PVC
Cleaning roller and cleaning card are included

Seaory S series black monochrome ribbon Specification.pdf

Seaory S series gold monochrome ribbon

Suitable for Seaory S20 S21 S22 S22K card printers
gold monochrome ribbon are primarily used for printing text and one-color line art on one or both sides of a card
Size:100mx60mm
1000 monochrome prints per roll (ISO CR80 53.98mm×85.60m)
Printing card material:PVC or Composite PVC
Cleaning roller and cleaning card are included

Seaory S series gold monochrome ribbon Specification.pdf

Seaory S series white monochrome ribbon

Suitable for Seaory S20 S21 S22 S22K card printers
white monochrome ribbon are primarily used for printing text and one-color line art on one or both sides of a card
Size:100mx60mm
1000 monochrome prints per roll (ISO CR80 53.98mm×85.60m)
Printing card material:PVC or Composite PVC
Cleaning roller and cleaning card are included

Seaory S series white monochrome ribbon Specification.pdf

Seaory S series silver monochrome ribbon

Suitable for Seaory S20 S21 S22 S22K card printers
silver monochrome ribbon are primarily used for printing text and one-color line art on one or both sides of a card
Size:100mx60mm
1000 monochrome prints per roll (ISO CR80 53.98mm×85.60m)
Printing card material:PVC or Composite PVC
Cleaning roller and cleaning card are included

Seaory S series silver monochrome ribbon Specification.pdf

Seaory S Series UV Ultraviolet Security Ribbon

Suitable for Seaory S20 S21 S22 S22K card printers
silver monochrome ribbon are primarily used for printing text and one-color line art on one or both sides of a card
Size:100mx60mm
1000 monochrome prints per roll (ISO CR80 53.98mm×85.60m)
Printing card material:PVC or Composite PVC
Cleaning roller and cleaning card are included

UV Ultraviolet Security Printing Application Technology.pdf

Seaory S series red monochrome ribbon

Suitable for Seaory S20 S21 S22 S22K card printers
Red monochrome ribbon are primarily used for printing text and one-color line art on one or both sides of a card
Size:100mx60mm
1000 monochrome prints per roll (ISO CR80 53.98mm×85.60m)
Printing card material:PVC or Composite PVC
Cleaning roller and cleaning card are included

Seaory S series red monochrome ribbon Specification.pdf

Seaory S series KO ribbon

Suitable for Seaory S20 S21 S22 S22K card printers
KO monochrome ribbon are primarily used for printing text and one-color line art on one or both sides of a card
Ribbon panels:Full size Black resin-K ,Overlay-O panels
500 monochrome prints per roll (ISO CR80 53.98mm×85.60m)
Printing card material:PVC or Composite PVC
Cleaning roller and cleaning card are included

Seaory S series KO ribbon Specification.pdf
